AGP11 MEMS Diffusion Silicon Stainless Steel Corrosion-resistant Pressure Resistance Vacuum Gauge High-precision Digital Vacuum Gauge

Model Number : AGP11

Place of Origin : CN

MOQ : 1PCS

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000PCS

Delivery Time : 5-8 work days

Packaging Details : Standard packaging

Accuracy : ±0.5%FS

Power Supply Voltage : 9 - 24VDC

Response Time : 50ms

Over - load Pressure : 300kpa

Load Resistance : 10kΩ

Operating Temperature : 5-45°C

Contact Now

AGP11 MEMS Diffusion Silicon Stainless Steel Corrosion-resistant Pressure Resistance Vacuum Gauge High-precision Digital Vacuum Gauge

Product Overview:

The AGP11 series is a piezoresistive vacuum gauge. It adopts a high - precision and high - stability diffused silicon oil - filled sensor core, and an integrated module design of an electronic controller and a sensor. By utilizing the piezoresistive effect of semiconductor materials and good elastic deformation performance, and relying on exquisite packaging technology and a complete assembly process, the quality and performance of this product are ensured.

Key Features:

  • High - precision vacuum measurement.
  • Long - term stable and reliable performance.
  • Excellent corrosion - resistance and wear - resistance.
  • Fast response and no hysteresis.
  • Unaffected by gas types.
  • Provide analog voltage output, with the advantages of high precision, high stability, strong corrosion resistance, good repeatability, light weight, and low maintenance cost.

Technical Parameters:

  • Measurement range: It provides two standard ranges, 0 - 100 Torr and 0 - 1000 Torr.
  • Response time: Only 50ms.
  • Output signal: Support 4 - 20mA current loop and 0 - 10V voltage signal output.
  • Sensor core material: High - quality 316 stainless steel.
  • Shell and interface: The surface of the shell and KF16 flange interface is electropolished, which improves the finish and further enhances the corrosion - resistance and wear - resistance.

Application Fields:

Suitable for medium and low vacuum degree measurement scenarios, such as vacuum baking, vacuum packaging, vacuum welding, vacuum coating, metal smelting, photovoltaic equipment and other industrial fields.

Measuring Range 0 - 100
0 - 1000		 Torr Two standard ranges
Accuracy ±0.5%FS - -
Power Supply Voltage 9 - 24 VDC -
Output Signal 0 - 10VDC
4 - 20mA		 - -
Response Time 50 ms -
Over - load Pressure 300 kPa -
Load Resistance 10 kΩ -
Operating Temperature 5 - 45 °C -
Storage Temperature - 5 - 60 °C -
Materials Exposed to Vacuum 304 Stainless Steel, 316 Stainless Steel - -
Connection Method KF16 - -
Weight 180 g

AGP11 MEMS Diffusion Silicon Stainless Steel Corrosion-resistant Pressure Resistance Vacuum Gauge High-precision Digital Vacuum Gauge
